DLW-300LSW2

Superior Performance: The DLW series silent diesel engine-driven DC welder and built-in AC generator offers exceptional welding performance combined with unmatched power stability.
Dual Operation: Supports simultaneous welding, allowing two operators to work at the same time.
Eco-Friendly Engine: Equipped with a Closed Breathing System to prevent blow-by gases from escaping, ensuring a cleaner engine operation.
Idle Control System: Designed to reduce noise and save fuel. The control unit automatically lowers engine speed during no-load conditions, enhancing fuel efficiency and minimizing noise pollution.
Simplified Maintenance: Inspection and maintenance can be performed easily from a single side of the unit. Additionally, the radiator can be cleaned effortlessly by removing the front panel.
Maintenance-Free Generator: The generator design eliminates the use of brushes or slip rings, resulting in a completely maintenance-free operation.
Advanced Safety Protection: Features multiple safety systems, including automatic circuit breakers for DC output overloads and various other protective monitors.

DC Welding Power
Rated Output	Single 8.74 kW Dual 3.58 x 2 kW
Rated Current	Single 280 A Dual 140 A
Rated Voltage	Single 31.2 V Dual 25.6 V
Welding Current Range	Single 60 – 300 A Dual 30 – 160 A
Welding Voltage Range	–
Rated duty	100 %
Applicable electrode	Single 2.0 – 6.0 mm Dual 2.0 – 3.2 mm
Generator Output
No. of Phase	3-Phase, 4wire
Power Factor	0.8 (Lagging)
Rated Output	11.4 kVA
Rated Voltage	380(380-440) V
Engine
Manufacturer	KUBOTA
Fuel Tank Capacity	36 L
Fuel Consumption	2.49 L/h
Units
Dimensions LxWxH	1410x560x770 mm
Weight	375 kg
Features
Welding Characteristics	Welding Mode Selector switch: DROOP/CC
Welding Characteristics	Arc Force Regulator
Improves Work Efficiency	Dual Operator Welding
Improves Work Efficiency	AVR
Fuel Reduction	e-mode(3 Position)
Safety Device	Non-stick Welding function
Safety Device	Voltage Reduction Device (VRD)
