Model: BT22RT
Boom Type: Telescopic Boom
• Working height: 22.51 meters
• S.W.L: 454 kg
• Maximum working height: 16.68 meters
• Rotating platform can continuously rotate 360°
• Non-marking foam-filled tires
| Dimension | |
|---|---|
| Max. Working Height | 22.51 m |
| Max. Platform Height | 20.51 m |
| Max. Operating Range (+0.6m) | 16.68 m |
| Max. Up And Over Clearance | 10.16 m |
| Overall Length(Stowed) | 9.82 m |
| Overall Length(Transport) | 2.50 m |
| Overall Width(Stowed) | 2.65 m |
| Overall Height(Stowed) | 2.46 m |
| Platform Size (LxW) | 2.44×0.90 m |
| Turntable Tailswing | 1.19 m |
| Ground Clearance | 0.28 m |
| Wheelbase | 2.40 m |
| Tyres | 315/55D20 |
| Performance | |
| S.W.L | 454 kg |
| Max. Occupants | 3 |
| Gradeability | 45 % |
| Travel Speed(Stowed/Raised) | 6.0/1.1 km/h |
| Max. Working Slope(X/Y) | 5°/5° |
| Turret Rotation | 360° Continuous |
| Platform Rotation | 180° |
| Jib Movement | 135° |
| Turning Radius(Inside/Outside) | 1.62/2.62 m |
| Weight | |
| Overall Weight | 13200 kg |
| Power | |
| Diesel Engine | Deutz D2.9 L4 36.4kW |
| Diesel Tank | 135 L |
| Hydraulic Oil Tank | 165 L |
